Druckkraft | 5 t |
Hub | 15 mm |
Bauhöhe eingefahren | 45 mm |
Betriebsdruck max. | 700 bar |
Ölvolumen max. | 11 cm³ |
Wirksame Kolbenfläche | 7.2 cm² |
Zylinderaußendurchmesser | 41 mm |
Gewicht ca. | 0.9 kg |
Artikel-Nr.: | YALE-N11100001 |
Bild | Typ | Druckkraft | Hub | Bauhöhe eingefahren | Betriebsdruck max. | Artikel-Nr. | Preis (zzgl. ges. MwSt.) |
![]() | Universal-Zylinder YS 5 / 15 | 5 t | 15 mm | 45 mm | 700 bar | YALE-N11100001 | 247,22 € UVP |
![]() | Universal-Zylinder YS 5 / 25 | 5 t | 25 mm | 97 mm | 700 bar | YALE-N11100002 | 309,70 € UVP |
![]() | Universal-Zylinder YS 5 / 75 | 5 t | 75 mm | 157 mm | 700 bar | YALE-N11100003 | 334,69 € UVP |
![]() | Universal-Zylinder YS 5 / 127 | 5 t | 127 mm | 214 mm | 700 bar | YALE-N11100004 | 381,10 € UVP |
![]() | Universal-Zylinder YS 5 / 180 | 5 t | 180 mm | 267 mm | 700 bar | YALE-N11100005 | 429,29 € UVP |
![]() | Universal-Zylinder YS 10 / 25 | 10 t | 25 mm | 90 mm | 700 bar | YALE-N11100006 | 323,98 € UVP |
![]() | Universal-Zylinder YS 10 / 50 | 10 t | 50 mm | 125 mm | 700 bar | YALE-N11100007 | 350,75 € UVP |
![]() | Universal-Zylinder YS 10 / 100 | 10 t | 100 mm | 178 mm | 700 bar | YALE-N11100008 | 384,67 € UVP |
![]() | Universal-Zylinder YS 10 / 150 | 10 t | 150 mm | 250 mm | 700 bar | YALE-N11100009 | 441,79 € UVP |
![]() | Universal-Zylinder YS 10 / 200 | 10 t | 200 mm | 300 mm | 700 bar | YALE-N11100010 | 493,55 € UVP |
![]() | Universal-Zylinder YS 10 / 250 | 10 t | 250 mm | 352 mm | 700 bar | YALE-N11100011 | 541,75 € UVP |
![]() | Universal-Zylinder YS 10 / 300 | 10 t | 300 mm | 407 mm | 700 bar | YALE-N11100012 | 602,44 € UVP |
![]() | Universal-Zylinder YS 15 / 200 | 15 t | 200 mm | 310 mm | 700 bar | YALE-N11100017 | 687,23 € UVP |
![]() | Universal-Zylinder YS 15 / 250 | 15 t | 250 mm | 365 mm | 700 bar | YALE-N11100018 | 743,45 € UVP |
![]() | Universal-Zylinder YS 15 / 300 | 15 t | 300 mm | 420 mm | 700 bar | YALE-N11100019 | 820,21 € UVP |
![]() | Universal-Zylinder YS 15 / 350 | 15 t | 350 mm | 472 mm | 700 bar | YALE-N11100020 | 904,10 € UVP |
![]() | Universal-Zylinder YS 15 / 25 | 15 t | 25 mm | 110 mm | 700 bar | YALE-N11100013 | 438,22 € UVP |
![]() | Universal-Zylinder YS 15 / 50 | 15 t | 50 mm | 140 mm | 700 bar | YALE-N11100014 | 486,41 € UVP |
![]() | Universal-Zylinder YS 15 / 100 | 15 t | 100 mm | 190 mm | 700 bar | YALE-N11100015 | 538,18 € UVP |
![]() | Universal-Zylinder YS 15 / 150 | 15 t | 150 mm | 260 mm | 700 bar | YALE-N11100016 | 604,22 € UVP |
![]() | Universal-Zylinder YS 23 / 25 | 23 t | 25 mm | 116 mm | 700 bar | YALE-N11100021 | 522,11 € UVP |
![]() | Universal-Zylinder YS 23 / 50 | 23 t | 50 mm | 150 mm | 700 bar | YALE-N11100022 | 591,73 € UVP |
![]() | Universal-Zylinder YS 23 / 100 | 23 t | 100 mm | 202 mm | 700 bar | YALE-N11100023 | 641,71 € UVP |
![]() | Universal-Zylinder YS 23 / 160 | 23 t | 160 mm | 277 mm | 700 bar | YALE-N11100024 | 705,97 € UVP |
![]() | Universal-Zylinder YS 23 / 210 | 23 t | 210 mm | 330 mm | 700 bar | YALE-N11100025 | 814,85 € UVP |
![]() | Universal-Zylinder YS 23 / 250 | 23 t | 250 mm | 376 mm | 700 bar | YALE-N11100026 | 884,47 € UVP |
![]() | Universal-Zylinder YS 23 / 300 | 23 t | 300 mm | 428 mm | 700 bar | YALE-N11100027 | 979,97 € UVP |
![]() | Universal-Zylinder YS 23 / 345 | 23 t | 345 mm | 477 mm | 700 bar | YALE-N11100028 | 1.094,21 € UVP |
![]() | Universal-Zylinder YS 30 / 125 | 30 t | 125 mm | 245 mm | 700 bar | YALE-N11100029 | 1.143,29 € UVP |
![]() | Universal-Zylinder YS 30 / 200 | 30 t | 200 mm | 325 mm | 700 bar | YALE-N11100030 | 1.309,30 € UVP |
![]() | Universal-Zylinder YS 50 / 160 | 50 t | 160 mm | 285 mm | 700 bar | YALE-N11100033 | 1.351,25 € UVP |
![]() | Universal-Zylinder YS 50 / 320 | 50 t | 320 mm | 460 mm | 700 bar | YALE-N11100034 | 1.781,43 € UVP |
![]() | Universal-Zylinder YS 50 / 50 | 50 t | 50 mm | 170 mm | 700 bar | YALE-N11100031 | 1.118,30 € UVP |
![]() | Universal-Zylinder YS 50 / 100 | 50 t | 100 mm | 220 mm | 700 bar | YALE-N11100032 | 1.215,59 € UVP |
![]() | Universal-Zylinder YS 70 / 150 | 70 t | 150 mm | 285 mm | 700 bar | YALE-N11100035 | 2.015,27 € UVP |
![]() | Universal-Zylinder YS 70 / 330 | 70 t | 330 mm | 490 mm | 700 bar | YALE-N11100036 | 2.636,45 € UVP |
![]() | Universal-Zylinder YS 100 / 100 | 100 t | 100 mm | 275 mm | 700 bar | YALE-N11100476 | 2.265,17 € UVP |
![]() | Universal-Zylinder YS 100 / 200 | 100 t | 200 mm | 375 mm | 700 bar | YALE-N11100037 | 2.607,89 € UVP |
